Sample.h File Reference

#include <QtGlobal>
#include <limits>
#include <sys/types.h>

Include dependency graph for Sample.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Macros
#define	SAMPLE_INDEX_MAX   ( std::numeric_limits<sample_index_t>::max() )
#define	SAMPLE_BITS   24
#define	SAMPLE_STORAGE_BITS   (sizeof(sample_storage_t) * 8)
#define	SAMPLE_MIN   (-(1 << (SAMPLE_BITS - 1)) + 1)
#define	SAMPLE_MAX   (+(1 << (SAMPLE_BITS - 1)) - 1)

Typedefs
typedef quint64	sample_index_t
typedef qint32	sample_t
typedef qint32	sample_storage_t

Functions
static sample_t	float2sample (const float f)
static float	sample2float (const sample_t s)
static double	sample2double (const sample_t s)
static sample_t	double2sample (const double f)

Macro Definition Documentation

SAMPLE_BITS

#define SAMPLE_BITS   24

number of significant bits per sample

Definition at line 43 of file Sample.h.

Referenced by Kwave::AudiofileDecoder::decode(), Kwave::WavDecoder::decode(), decode_linear(), decode_NULL(), double2sample(), Kwave::TrackPixmap::drawOverview(), Kwave::WavEncoder::encode(), Kwave::FlacEncoder::encode(), encode_linear(), float2sample(), Kwave::OggDecoder::parseHeader(), Kwave::MP3Decoder::parseMp3Header(), Kwave::MP3Decoder::processOutput(), sample2double(), sample2float(), and Kwave::FlacDecoder::write_callback().

SAMPLE_INDEX_MAX

#define SAMPLE_INDEX_MAX   ( std::numeric_limits<sample_index_t>::max() )

the highest possible sample index

Definition at line 31 of file Sample.h.

Referenced by Kwave::OverViewWidget::calculateBitmap(), Kwave::TrackView::canHandleSelection(), Kwave::SignalView::canHandleSelection(), Kwave::SignalView::dragEnterEvent(), Kwave::SignalView::dragLeaveEvent(), Kwave::SignalView::dragMoveEvent(), Kwave::SignalView::dropEvent(), Kwave::MetaData::lastSample(), Kwave::LabelList::nextLabelRight(), Kwave::SignalManager::openReader(), Kwave::TrackView::paintEvent(), Kwave::MetaDataList::scalePositions(), Kwave::SelectionTracker::selectRange(), Kwave::MetaDataList::shiftRight(), Kwave::OverViewWidget::showCursor(), Kwave::OverViewCache::slotInvalidated(), Kwave::SonagramPlugin::slotInvalidated(), Kwave::SelectionTracker::slotSamplesDeleted(), Kwave::SelectionTracker::slotSamplesInserted(), and Kwave::UndoAddMetaDataAction::UndoAddMetaDataAction().

SAMPLE_MAX

#define SAMPLE_MAX   (+(1 << (SAMPLE_BITS - 1)) - 1)

highest sample value

Definition at line 52 of file Sample.h.

Referenced by Kwave::OpusDecoder::decode(), decodeFrame(), Kwave::TrackPixmap::drawInterpolatedSignal(), Kwave::TrackPixmap::drawPolyLineSignal(), Kwave::OverViewCache::getMinMax(), Kwave::OverViewCache::getOverView(), Kwave::SampleReader::minMax(), Kwave::DebugPlugin::run(), Kwave::OverViewCache::scaleUp(), and Kwave::OverViewCache::slotTrackInserted().

SAMPLE_MIN

#define SAMPLE_MIN   (-(1 << (SAMPLE_BITS - 1)) + 1)

lowest sample value

Definition at line 49 of file Sample.h.

Referenced by Kwave::OpusDecoder::decode(), decodeFrame(), Kwave::OverViewCache::getMinMax(), Kwave::SampleReader::minMax(), Kwave::DebugPlugin::run(), Kwave::OverViewCache::scaleUp(), and Kwave::OverViewCache::slotTrackInserted().

SAMPLE_STORAGE_BITS

#define SAMPLE_STORAGE_BITS   (sizeof(sample_storage_t) * 8)

number of bits used for storing samples in integer representation

Definition at line 46 of file Sample.h.

Referenced by Kwave::AudiofileDecoder::decode(), Kwave::WavDecoder::decode(), Kwave::WavEncoder::encode(), Kwave::AudiofileDecoder::open(), and Kwave::WavDecoder::open().

Typedef Documentation

sample_index_t

typedef quint64 sample_index_t

use an unsigned integer for sample offset/count calculations

Definition at line 28 of file Sample.h.

sample_storage_t

typedef qint32 sample_storage_t

native data type used for storing a sample_t

Definition at line 40 of file Sample.h.

sample_t

typedef qint32 sample_t

Currently a "sample" is defined as a 32 bit integer with 24 significant bits

Definition at line 37 of file Sample.h.

Function Documentation

double2sample()

static sample_t double2sample ( const double  f )

inlinestatic

Simple conversion from double to sample_t

Definition at line 81 of file Sample.h.

References SAMPLE_BITS.

Referenced by Kwave::OpusDecoder::decode(), decodeFrame(), Kwave::Osc::goOn(), Kwave::CurveStreamAdapter::goOn(), Kwave::NoiseGenerator::input(), Kwave::Normalizer::input(), Kwave::LowPassFilter::input(), Kwave::NotchFilter::input(), Kwave::BandPass::input(), and Kwave::DebugPlugin::run().

                                                     {
    return static_cast<sample_t>(
        f * static_cast<double>(1 << (SAMPLE_BITS - 1)));
}

Here is the caller graph for this function:

float2sample()

static sample_t float2sample ( const float  f )

inlinestatic

Simple conversion from float to sample_t

Definition at line 57 of file Sample.h.

References SAMPLE_BITS.

Referenced by Kwave::RateConverter::input(), Kwave::PitchShiftFilter::input(), Kwave::Mul::multiply(), and Kwave::DebugPlugin::run().

                                                   {
    return static_cast<sample_t>(
        f * static_cast<float>(1 << (SAMPLE_BITS - 1)));
}

Here is the caller graph for this function:

sample2double()

static double sample2double ( const sample_t  s )

inlinestatic

Simple conversion from sample_t to double

Definition at line 73 of file Sample.h.

References SAMPLE_BITS.

Referenced by Kwave::NormalizePlugin::getMaxPowerOfTrack(), Kwave::NoiseGenerator::input(), Kwave::Normalizer::input(), Kwave::LowPassFilter::input(), Kwave::NotchFilter::input(), Kwave::BandPass::input(), Kwave::SonagramPlugin::makeAllValid(), and Kwave::NoiseDialog::updateDisplay().

                                                     {
    return static_cast<double>(
        static_cast<double>(s) / static_cast<double>(1 << (SAMPLE_BITS - 1)));
}

Here is the caller graph for this function:

sample2float()

static float sample2float ( const sample_t  s )

inlinestatic

Simple conversion from sample_t to float

Definition at line 65 of file Sample.h.

References SAMPLE_BITS.

Referenced by Kwave::RecordPlugin::checkTrigger(), Kwave::VorbisEncoder::encode(), Kwave::OpusEncoder::fillInBuffer(), Kwave::RateConverter::input(), Kwave::PitchShiftFilter::input(), Kwave::Mul::multiply(), and Kwave::LevelMeter::updateTrack().

                                                   {
    return static_cast<float>(
        static_cast<float>(s) / static_cast<float>(1 << (SAMPLE_BITS - 1)));
}

Here is the caller graph for this function:
